Flight Controller – F722 X8 36x36mm (3–8S)

  • MCU: STM32F722RET6 – high-speed processing for complex filters and precise PID tuning

  • IMU: ICM-42688 – low-noise, high-G gyro for rock-solid attitude hold

  • OSD: AT7456E – full Betaflight OSD overlay with customizable telemetry

  • Barometer: SPL06-001 – accurate altitude readings for GPS rescue and altitude control

  • Blackbox: 16MB onboard flash – deep flight data logging for fine-tuning

  • Input Voltage: 3–8S LiPo (11.4V–36V) – flexible for 3S to 8S setups

  • Dual BEC Outputs:

    • 5V / 2.5A – powers FC, receiver, GPS, and LEDs

    • 10V / 2A (USER1) – dedicated for high-power VTX and camera (clean, filtered output)

  • Extra Pad: IO2 (USER2) for additional accessories

  • Receiver Protocols: ELRS (CRSF), TBS Crossfire (CRSF), SBUS, iBUS, DSM2, DSMX

  • UARTs: 6x (UART1–6) – ample for GPS, compass, VTX control, and more

  • ESC Signal: PWM, Oneshot125/42, Multishot, DSHOT150/300/600

  • USB: Type-C – modern connectivity for firmware updates and Betaflight configurator

  • Firmware Target: AXISFLYINGF7PRO (Betaflight / INAV compatible)

  • Mounting: 30.5 x 30.5mm (4mm holes)

  • Weight: 8.8g
